Case Study
Arzanah Medical Complex
Project Overview
Building
Arzanah Medical Complex
Aeroseal Contractors
Trent Technical Services
Contract Engineer
Habtoor Leighton Group
Goal
Meet 8% leakage specifications
Before Aeroseal
Up to 50% or more of leakage
After Aeroseal
5% or less leakage
Results
Eliminated duct leakage in a 127,000 CFM system including all HVAC, exhaust and smoke extract systems
Type: Healthcare
International Medical Center Improves Hvac Airflow With Aeroseal
The multi-billion-dollar Arzanah Medical Center in Abu Dhabi was nearing completion and was ready to be the latest shining example of the United Arab Emirates’ architectural leadership. So it was with deep concern that engineers reviewed traverse readings taken from several of the structure’s HVAC risers that indicated leaks were robbing the facilities of half of the air traveling through the ductwork. Not only was this unacceptable from a building code perspective, but it also created significant concerns regarding indoor air quality, building performance, and energy costs.
I thought the Aeroseal technology was fantastic. I was expecting to find the entire inside of the ductwork coated with sealant. In fact, it just gathered around the holes to seal the leaks and left most of the internal ductwork free from sealant.
Kevin Waite
Test & Balancing Technician -
Trent Technical Services
“Aeroseal passed all of our criteria. First, it proved safe for use, even in a hospital environment. It then proved highly effective at sealing the system leaks. Aeroseal was so effective at eliminating leaks in the initial 15 risers targeted for sealing that we decided to expand the project to include the sealing of the building’s entire HVAC system, lab exhaust system, kitchen exhaust system and smoke extract system – a 127,000 CFM project in total.”
Gus Heber
Construction Director
Habtoor Leighton Group
When the leakage was first discovered, walls of the two five-story building structures were already constructed around the ductwork, making the leaks seemingly impossible to access without significant demolition. Engineers had even tried lowering workers down the risers in an effort to find and manually seal the multitude of leaks, but this proved to be hazardous and ineffective.
To Learn More About Improving The Comfort, Indoor Air Quality, and Energy Efficiency Of Your Building
CALL: 937-428-9300 or EMAIL: info@aeroseal.com
Results
An Internet search for a better solution led the engineering team to Aeroseal – a duct sealing technology that works from the inside to seal leaks. After the technology passed rigorous safety criteria, an Aeroseal team was brought in from the U.S. to demonstrate the technology on several leaking risers. Test results were so impressive that the building engineers decided to use Aeroseal throughout the complex, including the HVAC exhaust, the HVAC supply, the HVAC return, the lab exhaust, the kitchen exhaust, and the structure’s entire smoke extract system – a 127,000 CFM system in all. Work was completed in two weeks.
